Tone Master Pro
Tone Master Pro is the first no-compromise multi-effects guitar workstation that features the amazing sound quality that the Tone Master series is known for. Combining a powerfully intuitive interface and the most comprehensive I/O array available, the Tone Master Pro is the best sounding, most powerful and easiest to use guitar processor ever.

Tone Master Pro features over 100 of the world’s most popular amps and effects, including all of the classic Tone Master Fender models, the first officially licensed EVH 5150 III Stealth model, and other can’t live without classics that have all been perfectly replicated using our proprietary Tone Master Modeling process. Tone Master Pro’s lightweight, rugged, stage-friendly form factor is as beautiful as it is functional. With a full-color touchscreen, stunning graphics, and intuitive user interface, dialing in the perfect tone has never been easier or more inspired.

Create Presets, customize your footswitch assignments and combine them to create Songs and organize into Setlists with ease. Tone Master Pro’s 10 custom-designed footswitch encoders make editing a breeze, giving you instant access to all your presets and parameters and make adjustments just like you would on the real thing. Connect to our Tone Master Pro Control app via USB for creating, editing and sharing your own presets or for auditioning and downloading thousands of tones created by Fender’s community of players and artists.

Features
Over 100 Tone Master quality Amp & Effect Models
Over 6000 Fender-captured Impulse Responses with a variety of cabinet and microphone options
3rd Party IR support
7″ Color Touch-screen
Innovative Song & Setlist modes
60 second Stereo Looper
4 Effects Loops for integrating your favorite pedals
Instrument and XLR mic inputs
10 proprietary footswitch/encoders with LCD “scribble strips”
True preset spillover of delay and reverb tails for seamless preset changes
Firmware updates over USB
Compatible with Tone Master Pro Control desktop app for editing, sharing and downloading presets
Over 500 User Presets with access to thousands more from the Cloud using the Tone Master Pro Control App
Bluetooth wireless connection for streaming audio from a mobile device
Stereo 1/4″ Headphone output jack for silent practice
Compatible with the Mission Engineering SP1-TMP Expression Pedal for realtime control of parameters

Specs
Electronics
Control Panel Navigation Control, Master Volume Control, 10 Footswitch/Encoders with LCD “Scribble Strips”
Effects Over 100 Quality Amp and Effect Models
Effects Loop 4 Total
Effects Loop Connection Type Mono Loops (1 & 2) 1/4″ Unbalanced, Mono Loops (3 & 4) 1/4″ TRS Balanced (Can Be Combined into Stereo Pair)
Effects Loop Impedance 10 kΩ
Voltage 230V UK
Power Requirements 40W
Connectivity USB-C®
Phantom Power +48 VDC (XLR Only)
Digital Audio Bit Depth 32 Bit
Digital Audio Frequency Response 20 Hz – 20 kHz (+0.1/-0.7 dB)
Supported Sample Rates 44.1 kHz Internal (Project Sync 44.1/48/88.2/96 kHz)
Looper 60-Second Stereo Looper
Other Connections 1/4″ Expression Pedal 1 and 2, Amp Control
MIDI I/O Dual 5-Pin DIN (In/Out-Through-Merge)

Inputs
Microphone Input Connection Type XLR Female (Combo), Balanced
Microphone Preamp Maximum Input Level 4.7V
Microphone Preamp Input Impedance 1.8 kΩ Balanced
Instrument Inputs Maximum Level 5.6V (2.8V with Input Pad Off)
Instrument Inputs Impedance 1 MΩ, 330 kΩ, 22 kΩ Configurable Unbalanced
Instrument Input Connection Type 1/4″
Line Inputs Maximum Level 7.8V Balanced, 4.5V Unbalanced
Line Inputs Impedance 1MΩ
Line Input Connection Type 1/4” TRS Female (Combo), Balanced
Auxiliary Input Connection Type 3.5 mm Stereo
Auxiliary Input Impedance 10 kΩ
Auxiliary Input Max Input Level 2.4V

Outputs
Headphone Outputs Maximum Output 110mW x2
Headphone Outputs Impedance Working Range 33Ω x2 (16Ω x2 Minimum)
Headphone Outputs Connection Type 1/4” TRS Stereo, Unbalanced
Line Outputs Connection Type 1/4” TRS Female, Balanced (Stereo Pairs Output 1 and 2)
Line Outputs Maximum Output Level Output 1 – 12V (Line) 3.9V (Instrument), Balanced; 6.1V (Line) 2.8V (Instrument), Unbalanced; Output 2 – 4.7V (Line) 2.8V (Instrument)
Line Outputs Output Impedance Output 1 – 200Ω (Line) 290Ω Balanced, 400Ω Unbalanced (Instrument); Output 2 – 170Ω
XLR Outputs Connection Type XLR Male, Balanced (Stereo Pair)

Miscellaneous
Legal Notice WARNING: Cancer and Reproductive Harm
Color Black

Accessories
Footswitch Connection Type 1/4″

Measurement
Height 3.8″ (96.4 mm)
Width 14.6″ (37.1 cm)
Depth 10.3″ (26.16 cm)
Weight 8.8 lbs (4 kg)
