Ibanez BTB605MS CEM Multiscale Bass Workshop Series Bass Guitar 5 String wtih Gig Bag

Ibanez BTB605MS CEM Multiscale Bass Workshop Series Bass Guitar 5 String wtih Gig Bag

SPECS
neck type BTB 5 for Multi Scale 5pc Maple/Walnut w/Graphite reinforcement rods Neck-through
top/back/body Okoume wing body
fretboard Bound Panga Panga fretboard Abalone dot inlay
fret Medium Stainless Steel frets
number of frets 24 (+ zero fret)
bridge MR5S bridge
string space 18mm
neck pickup T1 neck pickup Passive
bridge pickup T1 bridge pickup Passive
equaliser Ibanez Custom Electronics 3-band EQ w/ EQ bypass switch (passive tone control on treble pot) & 3-way Mid frequency switch
factory tuning 1G,2D,3A,4E,5B
strings D’Addario NYXL45130 for 37″
string gauge .045/.055/.080/.100MS/.130MS
hardware color Black

NECK DIMENSIONS
Scale : 939.8mm/37″ – 889mm/35″
a : Width 47mm at NUT
b : Width 75mm at 24F
c : Thickness 20mm at 1F
d : Thickness 22mm at 12F
Radius : 400mmR

CONTROLS
BTB605MS’s control diagram

FREQUENCY RESPONSE
BTB605MS’s EQ curve diagram

OTHER FEATURES
Recommended Bag IBB540-BK
Hardshell case included

Features

Okoume wing body
The Okoume wing body provides a bright and solid sound.

Medium Stainless Steel frets
The Stainless Steel frets are durable and long-lasting.

T1 pickups
The T1 pickup is a humbucker featuring two separate, individually mounted coils that provides tight bass response, punchy mid-range, and clear high-end. It offers flexible voicing suitable for various genres, and the height of each coil can be set individually for highly nuanced adjustments to the tone. On top of its great sound, the physical design features rounded edges for enhanced ergonomic comfort when using the pickup as a thumb rest. Moreover, the individually mounted coils allow them to be positioned slightly offset from one another. This makes it so the surface of the pickup where the player rests their thumb is directly parallel with the strings, which is not typical with most multi scale basses. This design greatly enhances the comfort and playability of the instrument.

Neck-through construction
The neck-through construction contributes to massive sustain and smooth access to high fretboard positions.

5pc Maple/Walnut neck with Graphite reinforcement rods
The 5pc Maple/Walnut neck provides tonal clarity and superior attack.The Graphite reinforcement rods provides massive sustain and excellent stability.

MR5S bridge
The MR5S bridge has adjustable saddles for variable string spacing by +/- 1.5mm, answering every bassist’s specific string spacing needs.

Ibanez Custom Electronics 3-band EQ w/EQ bypass switch & Mid frequency switch
Ibanez Custom Electronics 3-band EQ is our latest refinement on the concept of simple, straightforward, no-nonsense EQ control. The Boost and Cut for the Mid Control are each centered on slightly different frequencies, an innovation that delivers a preset range of the most favorable bass tones.
Precision tonal control, including a switch to choose passive-only operation. When the EQ bypasses activated, the treble tone control knob becomes the global tone control for the passive circuit.

Panga Panga fretboard
Panga Panga features a beautiful wood grain which produces a tight low and mid range, along with a sharp attack on high end.
